Laughing gas devices Baldus analog
The analogue nitrous oxide mixer Baldus Analog fits into any modern practice, is extremely light and safe to use. You do not need a power connection for analogue nitrous oxide sedation and can sedate completely independently.
When developing the analog nitrous oxide device, the focus was on safety and robustness as well as handling.
Designed in germany! Made in Germany!
Here are some of the advantages of our nitrous oxide flow meters:
The patient is comfortably sedated by a possible total flow of 15l/min and always has enough air to breathe. Important safety features of nitrous oxide sedation include the Nitrolock, which prevents the release of nitrous oxide without oxygen.
The integrated oxygen failure warning tone and the central placement of the O2 flush button for an immediate oxygen flood. These were not all the safety systems of our sedation, so the nitrous oxide sedation has an easily accessible connection for an O2 emergency ventilation mask on the side of the nitrous oxide device.
The Bag-T has a non-return valve that prevents rebreathing into the breathing bag and an emergency opening valve should the breathing bag be completely empty by your patient. As a result, your patient always has a supply of breathing air.
All displays of the nitrous oxide sedation can be read easily and quickly by the dentist and his team. Handling an analogue nitrous oxide system has never been as safe and easy as with our Baldus analogue.
Baldus Analog details
Highlights: Baldus analog nitrous oxide device
- Made in Germany
- Control with one button operation
- acoustic warning tones in case of O2 deficiency
- Tamper-proof
- Nitrous oxide stop in case of oxygen failure
- Total flow 15l / min.
- O2 flush button placed in the middle
- Simply read off the N2O concentration
- Precise flow meters for easy operation
- Easy cleaning
- Limited to 50% max. 70%
- High quality material
- Almost indestructible!
- 92% stainless steel and aluminum
- Automatic fresh air supply
- No power supply
- Connection for emergency respiratory mask
- Gas type coding
- CE and FDA certified
Description
- Intelligent arrangement of the valve for fresh air intake
- Max. Mixing ratio selectable between 50%, 60% or 70% N2O (standard delivery 70%)
- Automatic adjustment of the output flow (one-button operation)
- ISO color coding for EU
- Oxygen flush for immediate oxygen supply – best accessibility thanks to its “red” color on the front of the device
- Premium security package
- check valve
- Rebreathing stop (with empty breathing bag)
- Connection for O2 demand mask
- Standard-compliant coding of the gas types
- US Patented No. 10,065,1590B2
This is included in the package:
- “Baldus Analog” nitrous oxide device
- Baldus Adult Double Nose Mask Scavenger System, including 3 x Disposable Adult Double Nose Masks Blueberry and 3 x Disposable Children’s Double Nose Masks Strawberry, plus a complete tubing set with connectors.
- Baldus vacuum control block with inline flow measurement
- Breathing bag 3 liters, latex-free and autoclavable
- Ultraslim cylinder pressure regulator O2 incl. Med. Fabric hose
- Ultraslim cylinder pressure regulator N2O incl. Med. Fabric hose
- All-in-One-Cart Ultra-Slim, fully clad trolley for Baldus Touch or Analog, dimensions: 108 x 38.5 x 29 cm, 25 kg, color: matt white
- Marketing package: waiting room film, patient flyer, images, medical product book
Additional information
| N2O limitation | 70%, 50%, 60% |
|---|---|
| Maximum total flow | 15 l / min |
| Security package | Premium |
| warranty | 5 year guarantee on conclusion of a maintenance contract |
